Product Description

We are providing our esteemed clients with excellent quality of S Type Load Cells. These load cells are manufactured using high-grade raw material and modern machinery by our skilled engineers. The offered load cells are available in different models and other related specifications, in order to meet variegated expectations of our valuable customers. Our provided range is rigorously tested by the team of our professionals. Furthermore, our clients can avail these load cells from us at market leading prices.

Specifications:

Standard Capacities:- 80-Kgf

Excitation Voltage:- 10VDC-Max. 15VDC

Normal Output:- 2.0 mV/V

Non Linearity:- < ± 0.025% FSO

Hysteresis:- < ± 0.02% FSO

Non Repeatability:- < ± 0.01% FSO

Creep (30 minutes):- < ± 0.03% FSO

Zero balance:- ± 1.0% FSO

Input Resistance:- 400 ± 15 Ohms

Output Resistance:- 350 ± 5 Ohms

Insulation Resistance (50VDC):- > 1000 Mega Ohms

Cable Length (4 Core Screened):- 45Cm.

Safe Overload of Related Capacity:- 150%

Ultimate Overload of Rated Capacity:- 200%

Temp Compensated Range:- 0-60ºC

Temprature Effect on Output:- < 0.0015% FSO/ºC

Temprature Effect on Zero:- < 0.0020% FSO/ºC

Platter Size:- 300mm x 300mm

Eccentric Load Effect:- < 0.02% of FSO at 1/3 rated load placed within the specified sized platter

Deflection;- <0.5mm at FSO

Tightening Torque:- 2 m.Kg

Finish & Construction:- Alluminium Alloy

Environmental Protection Class:- lp65

Applications:- Bench, Counting Postal Scales, Check Weighers

Standard Capacities:- 80-Kgf

Excitation Voltage:- 10VDC-Max. 15VDC

Normal Output:- 2.0 mV/V

Non Linearity:- < ± 0.025% FSO

Hysteresis:- < ± 0.02% FSO

Creep (30 minutes):- < ± 0.03% FSO

Zero balance:- ± 1.0% FSO

Input Resistance:- 400 ± 15 Ohms

Output Resistance:- 350 ± 5 Ohms

Insulation Resistance (50VDC):- > 1000 Mega Ohms

Cable Length (4 Core Screened):- 45Cm.

Safe Overload of Related Capacity:- 150%

Ultimate Overload of Rated Capacity:- 200%

Temp Compensated Range:- 0-60ºC

Temprature Effect on Output:- < 0.0015% FSO/ºC

Temprature Effect on Zero:- < 0.0020% FSO/ºC

Platter Size:- 300mm x 300mm

Eccentric:- Load Effect < 0.02% of FSO at 1/3 rated load placed within the specified sized platter

Deflection:- <0.5mm at FSO

Tightening Torque:- 2 m.Kg

Finish & Construction:- Alluminium Alloy

Environmental Protection Class:- lp65

Applications:- Bench, Counting Postal Scales, Check Weighers
