Product Description

With firm commitment to quality, we manufacture, export and supply a wide assortment of Shear Beam Load Cell. These load cells are widely demanded by our clients for their excellent design, easy and reliable operation. The offered load cells are available in various specifications, as per the requirements of our esteemed clients. High grade raw material is used by the engineers, along with contemporary production equipment to manufacture the entire range.

Specifications:

Standard Capacities:- 100, 150, 200, 300, 500, 750, -Kgf 1,2, 3, 5, - Tf

Excitation Voltage:- 10VDC-Max. 15VDC

Normal Output:- 3.0 mV/V

Non Linearity:- < ± 0.025% FSO

Hysteresis:- < ± 0.02% FSO

Non Repeatability:- < ± 0.01% FSO

Creep (30 minutes):- < ± 0.03% FSO

Zero balance:- ± 1.0% FSO

Input Resistance:- 390 ± 3.5 Ohms

Output Resistance:- 350 ± 3.5 Ohms

Insulation Resistance (50VDC):- > 1000 Mega Ohms

Cable Length (4 Core Screened):- 500 Cm.

Safe Overload of Related Capacity:- 150%

Ultimate Overload of Rated Capacity:- 300%

Allowable Side Load:- 50%

Side Load Discrimination:- 500..1

Temp Compensated Range:- 0-60ºC

Temprature Effect on Output:- < 0.0015% FSO/ºC

Temprature Effect on Zero:- < 0.0020% FSO/ºC

Deflection:- < 0.5mm at FSO

Tightening Torque:- 5 m.Kg

Finish & Electroless Nickel Plated Steel Alloy

Construction:- lP67

Environmental Protection Class:- Low Profile Floor Scales, Tank, Hopper, Bag Weigh, Pallet Scale, Industrial Automation

Technical Specifications:

100kg

200kg

300kg

500kg

750kg
